YLDG-V Stainless Steel Arc Shaped Light Pole
- Model:
- Materials:
- Height:
- Min. Diameter:
- Max. Diameter:
- Wall Thickness:
- Wind Resistant:
- YLDG-V
- 304/L 316/L Stainless Steel
- 3-12 Meters | 10-40 Feet
- 60MM | 2.36 Inches
- 255MM | 10 Inches
- 2.5-6.0MM | 0.1-0.25 Inches
- 180KM/H
Stainless Steel Arc Shaped Light Pole Specification
| MODEL | HEIGHT | TOP OD | BASE OD | HEIGHT2 | HEIGHT3 | ARM | THICK | DOOR HEIGHT | BASE SIZE |
|---|---|---|---|---|---|---|---|---|---|
| YLDG-V1 | 5000 | 76 | 152 | 1000 | 4500 | 1500 | 4.0 | 500 | 298x298x12 |
| YLDG-V2 | 6000 | 76 | 152 | 1000 | 5500 | 1500 | 4.0 | 500 | 298x298x12 |
| YLDG-V3 | 7000 | 76 | 166 | 1200 | 6500 | 1800 | 4.0 | 500 | 298x298x12 |
| YLDG-V4 | 8000 | 76 | 180 | 1200 | 7500 | 1800 | 4.0 | 500 | 305x305x19 |
| YLDG-V5 | 9000 | 76 | 180 | 1500 | 8500 | 2000 | 4.0 | 500 | 305x305x19 |
| YLDG-V6 | 10000 | 76 | 200 | 1500 | 9500 | 2000 | 4.0 | 500 | 305x305x19 |
Surface Treatment
1. Powder Coating
Purpose: Adds color, improves aesthetics, and provides an extra layer of protection.
Process: Electrostatic application of dry powder, then cured under heat.
Benefits:
– UV-resistant, preventing fading.
– Scratch and chip-resistant.
– Wide range of color options.
– Best for: Urban, coastal, or high-visibility areas.
2. Electroplating
Purpose: Improves corrosion resistance and adds a shiny metallic finish.
Process: Electrolytic deposition of metal (e.g., chrome, nickel, or zinc).
Benefits:
– High luster for decorative appeal.
– Extra corrosion protection.
– Best for: High-end architectural applications.
Description
Designed to blend artistry with functionality, our Arc Shaped Light Pole transforms ordinary lighting into striking urban landmarks. Crafted from marine-grade 304/316L stainless steel, its graceful curve creates ambient light diffusion while resisting harsh environments.
Design Highlights
Signature Arc Profile
Smooth 90°-180° curvature** for dramatic light projection
Radius customization (2m-5m typical)
Dual-side illumination capability
Aerospace-Grade Materials
– 316L stainless steel standard for coastal/industrial use
– Mirror polish or brushed satin finishes
– 6mm-12mm wall thickness** (tapered construction)
Smart Engineering
– Integrated LED mounting channels
– Internal wiring conduits (IP66 rated)
– Wind-tested to 180km/h
Premium Applications
– Luxury waterfront promenades
– 5-star resort lighting
– Signature city squares
– High-end commercial districts
– UNESCO heritage sites
Customization Options
– Warm white/Cool white LED integration
– Glass or aluminum diffusers
– Interactive lighting controls
– Gold PVD or black oxide finishes
