Traffic Light Pole Manufacturer
Custom traffic light poles and signal structures configured for intersection geometry, arm length, signal and sign loads, mounting details, local wind criteria, exposure conditions, and the approved project specification.
Anti-Corrosion
Hot-dip galvanized + powder coated for 25+ year service life in coastal and industrial zones
Modular Design
Interchangeable arms, brackets, and signal heads for flexible configurations
Wind Rated
Engineered to withstand wind speeds up to 160 km/h (Category 2 hurricane)
Smart Ready
Integrated cable channels and mounting points for cameras, sensors, and 5G equipment
Eco Certified
100% recyclable materials, low-emission manufacturing process, LEED compatible
Dual-Alloy Construction for Maximum Durability
Each pole leverages the best properties of two metals — the structural integrity of stainless steel with the lightweight corrosion resistance of aluminum alloy.
Stainless Steel (SS304 / SS316)
Base structure and critical load-bearing joints use marine-grade stainless steel for exceptional tensile strength, impact resistance, and long-term structural stability under dynamic loads.
Aluminum Alloy 6063-T6
Upper pole sections, signal arms, and mounting brackets use heat-treated aluminum alloy — 40% lighter than steel with natural oxide layer protection, reducing installation weight and foundation requirements.
Surface Treatment
All components undergo hot-dip galvanization followed by electrostatic polyester powder coating (80-120μm) for a UV-stable, scratch-resistant finish available in RAL color matching.
Designed for Rapid Urban Integration
The traffic light pole features a flange-mounted base plate system with pre-wired internal channels, enabling installation in under four hours with a standard three-person crew and crane.
Foundation Options
Direct embedment, base plate on concrete pier, or anchor bolt system for retrofit projects
Cable Management
Internal routing with inspection doors at 300mm intervals, waterproof IP68 junction boxes included
Compliance
EN 40 / ASTM A513 / AS/NZS 1170.2 certified. Municipal approvals available for 50+ countries
Maintenance Access
Hinged base option for tilt-down maintenance without crane, reducing lifetime OPEX by up to 60%
Specifications
Standard configuration. Custom specifications available for OEM and government procurement. Contact us for engineering consultation.
- Material — Pole Body
- Wall Thickness
- Height Range
- Base Plate
- Surface Treatment
- Wind Resistance
- Seismic Rating
- Protection Class
- Operating Temperature
- Cable Entry
- Certifications
- Warranty
- Stainless Steel SS304 / SS316 (base) + Aluminum Alloy 6063-T5 (upper)
- 3.0mm / 4.0mm / 5.0mm (model dependent)
- 6m / 8m / 9m / 10m / 12m (custom up to 15m available)
- 400×400mm / 500×500mm SS304, 16mm thick, 4-bolt pattern
- Hot-dip galvanized (85μm zinc) + Polyester powder coat (80-120μm), RAL color matching
- Up to 160 km/h (per AS/NZS 1170.2, Terrain Category 3)
- Zone IV compliant (per IBC 2018)
- IP66 (signal housing), IP54 (junction compartments)
- -40°C to +55°C
- Internal routing, M40/M50 cable glands, inspection doors (300mm spacing)
- EN 40-1 to EN 40-5, ASTM A513, ISO 9001:2015, CE, RoHS
- 15 years structural / 5 years powder coat finish / 3 years electronics
Configurable for Any Intersection
Traffic signal structures can be configured for the approved mounting height, mast-arm geometry, signal load, luminaire interface, foundation layout and finish. Coordinate wind-load design inputs and the anchor-bolt pattern with the project drawings before production.
Standard
Single-arm configuration for standard pedestrian crossings and residential intersections. Compact footprint with full signal integration.
Multi-Arm
Dual or triple-arm configuration for major intersections. Enhanced structural capacity for multiple signal heads, cameras, and smart city sensors.
Smart Hub
Full-size smart infrastructure pole with integrated 5G antenna mounts, environmental sensors, CCTV brackets, and EV charging readiness.
