- Model:
- Materials:
- Height:
- Min. Diameter:
- Max. Diameter:
- Wall Thickness:
- Wind Resistant:
- YLDG-G
- 6061 6063 T6 Aluminum Alloy
- 3-12 Meters
- 60 mm
- 255 mm
- 2.5-6.0 mm
- 180KM/H
- 10-40 Feet
- 2.36 Inches
- 10 Inches
- 0.1-0.25 Inches
High and Low Arms Light Pole Specification
The High and Low Arms Light Pole shaft is crafted from precision-spun, seamless 6063 T6 aluminum alloy tubing.
| MODEL | HEIGHT | TOP OD | BASE OD | THICK | ARM L1 | ARM L2 | DOOR HEIGHT | BASE SIZE |
|---|---|---|---|---|---|---|---|---|
| YLDG-G1 | 5000 | 76 | 152 | 4.0 | 1500 | 800 | 500 | 298x298x12 |
| YLDG-G2 | 6000 | 76 | 152 | 4.0 | 1500 | 800 | 500 | 298x298x12 |
| YDG-G3 | 7000 | 76 | 166 | 4.0 | 1500 | 800 | 500 | 298x298 x12 |
| YLDG-G4 | 8000 | 76 | 180 | 4.0 | 1500 | 800 | 500 | 305x305 x19 |
| YLDG-G5 | 9000 | 76 | 180 | 4.0 | 1500 | 800 | 500 | 305x305x19 |
| YLDG-G6 | 10000 | 76 | 200 | 4.0 | 1500 | 800 | 500 | 305x305x19 |
Anchor Base
The anchor base is cast from A356 alloy aluminum.
The completed assembly is heat-treated to a T6 temper.
Aluminum nut covers are included with anchor base unless otherwise specified
| MODEL | BASE OD | BASE SIZE | THICK | HOLE SPACING |
|---|---|---|---|---|
| YLDG-PB1 | 152 | 260 x 260 | 12 | 210x210 |
| YLDG-PB2 | 166 | 285 x 285 | 19 | 210x210 |
| YLDG-PB3 | 180 | 305 x 305 | 19 | 210x210 |
| YLDG-PB4 | 200 | 305 x 305 | 19 | 210x210 |
Anchor Bolts
Anchor bolts conform to ASTM F1554 Grade 55 and are provided with two hex nuts and two flat washers.
Bolts have an “L” bend on one end and are galvanized a minimum of 12″ on the threaded end
Base Cover
Optional round or square base cover available as special orderprovided
Surface Treatments
We focus on superior surface treatments to ensure long-lasting durability and aesthetic appeal for outdoor environments. Our products feature two primary finishing options:
Anodizing (30μm)
This electrochemical process creates an extremely hard, integral oxide layer on the aluminum surface. It offers outstanding corrosion and fade resistance, maintaining a classic metallic look in finishes such as champagne, bronze, and black. Anodizing is known for its exceptional longevity and weather resistance.
Powder Coating (60~80μm)
This process applies a dry, free-flowing powder electrostatically, which is then cured to form a tough, protective film. Powder coating provides superior flexibility in colors and textures, excellent impact resistance, and a durable barrier against the elements. It is the ideal choice for vibrant colors and enhanced design coordination.







Aluminum high and low light poles offer a superior alternative to traditional steel, primarily due to their exceptional corrosion resistance. Unlike steel, aluminum naturally forms a protective oxide layer that never rusts, making these poles ideal for coastal regions, chemical plants, and high-humidity environments where painted or galvanized steel would eventually deteriorate. This inherent property eliminates the need for costly hot-dip galvanizing or periodic repainting, resulting in decades of virtually maintenance-free service.
Another critical advantage is weight. Aluminum is approximately sixty percent lighter than steel, which dramatically reduces shipping costs and simplifies installation. A single crew can handle and erect aluminum poles without heavy cranes or specialized lifting equipment, significantly lowering labor expenses and project timelines. Despite this lightweight nature, aluminum poles are remarkably strong and ductile. When subjected to high winds or accidental vehicle impacts, aluminum flexes rather than cracks or snaps like brittle steel, offering superior structural resilience and safety in hurricane zones or along roadways.
Aesthetics also play a key role. Aluminum poles come with a smooth, seam-free surface that accepts powder-coated and anodized finishes exceptionally well. These finishes remain vibrant and resist flaking or fading for many years, far outlasting painted steel. From an environmental standpoint, aluminum is infinitely recyclable and requires less energy to produce than galvanized steel, supporting green building certifications such as LEED. Finally, aluminum’s non-magnetic properties reduce eddy current losses in high-mast AC lighting systems, providing a small but meaningful improvement in electrical efficiency over the pole’s lifespan. For owners seeking long-term value, safety, and low total cost of ownership, aluminum light poles are an outstanding investment.
