Aluminum Alloy Round Tapred Light Pole
- Model:
- Materials:
- Height:
- Min. Diameter:
- Max. Diameter:
- Wall Thickness:
- Wind Resistant:
- Warranty ：
- YLDG-Z
- 6061 6063 T6 Aluminum Alloy
- 3-12 Meters | 10-40 Feet
- 60MM | 2.36 Inches
- 255MM | 10 Inches
- 2.5-6.0MM | 0.1-0.25 Inches
- 180KM/H
- 10+ Years
Pole Specification
| MODEL | HEIGHT | TOP OD | BASE OD | THICK | DOOR HEIGHT | DOOR SIZE | BASE SIZE |
|---|---|---|---|---|---|---|---|
| YLDG-Z1 | 3000 | 76 | 152 | 4.0 | 500 | 80×250 | 298x298x12 |
| YLDG-Z2 | 4000 | 76 | 152 | 4.0 | 500 | 80×250 | 298x298x12 |
| YLDG-Z3 | 5000 | 76 | 152 | 4.0 | 500 | 80×250 | 298x298x12 |
| YLDG-Z4 | 6000 | 76 | 152 | 4.0 | 500 | 80×250 | 298x298x12 |
| YLDG-Z5 | 7000 | 76 | 166 | 4.0 | 500 | 80×250 | 298x298x12 |
| YLDG-Z6 | 8000 | 76 | 166 | 4.0 | 500 | 80×250 | 298x298x12 |
| YLDG-Z7 | 9000 | 76 | 180 | 4.0 | 500 | 100×300 | 305x305x19 |
| YLDG-Z8 | 10000 | 76 | 200 | 4.0 | 500 | 100×300 | 305x305x19 |
Base Specification
| MODEL | BASE OD | BASE SIZE | THICK | HOLE SPACING |
|---|---|---|---|---|
| YLDG-PB1 | 152 | 298x298 | 12 | 210x210 |
| YLDG-PB2 | 166 | 298 x298 | 12 | 210x210 |
| YLDG-PB3 | 180 | 305 x305 | 19 | 210x210 |
| YLDG-PB4 | 200 | 305 x308 | 19 | 210x210 |
Surface Treatments
Superior Anodized Finish
1 Process
Electrolytic oxidation creates a hard, porous aluminum oxide layer
Sealed with nickel acetate for maximum corrosion resistance
Thickness: 20–25µm (Class I per ASTM B580)
Color Options:
Natural silver
Black/gold/bronze (custom Pantone matches available)
Stainless steel look (specialty finish for Korzovo project)
2 Material & Structural Benefits
6063-T6 alloy
High strength-to-weight ratio
Salt spray resistance
2000+ hours (ASTM B117)
UV stability
Zero fading for 15+ years
Non-conductive surface
Safer near power lines
3. Premium Applications
Urban landmarks (parks, campuses)
Coastal/harsh environments
High-end architectural lighting
Powder coating is an excellent finishing method for aluminum light poles, offering durability, corrosion resistance, and aesthetic appeal.
Process
Application:
– Electrostatic spray guns charge the powder particles, which adhere to the grounded aluminum pole.
– Uniform coverage is critical, especially for complex shapes.
Curing:
– Heat in an oven (~350–400°F / 177–204°C) for 10–15 minutes.
– The powder melts and forms a smooth, hard finish.
Quality Control & Testing
– Adhesion Test: ASTM D3359 (cross-cut tape test).
– Thickness Check: 2–4 mils (50–100 microns) is typical for light poles.
– Salt Spray Test: ASTM B117 (500+ hours for industrial/marine environments).
– Impact Resistance: ASTM D2794 (ensures durability against physical damage).
Description
A tapered light pole is a type of outdoor lighting pole that has a tapered shape, where the diameter of the pole decreases gradually from the base to the top, forming a cone-like structure. These poles are commonly used in urban and street lighting projects due to their sleek and modern appearance.
Tapered light poles are designed to provide structural stability, resistance to wind loads, and an aesthetic appeal to outdoor spaces. They are often made of materials like aluminum, steel, or fiberglass, depending on the specific requirements of the project.
These light poles are versatile and can accommodate a variety of lighting fixtures such as LED lights, traditional lamps, or decorative lighting elements. The tapered shape of the pole not only adds a contemporary look but also helps in efficiently distributing light across the area being illuminated.
Overall, tapered light poles are a popular choice for lighting projects that require a combination of functionality, durability, and visual appeal.
